- 1971 71 Camaro Factory Assembly Manual Z28 SS RS - 426 Pages!
Sold out.
Description:
1971 Camaro Factory Assembly Manual
A "Must Have" for anyone restoring, working on or even just owning a 71 Camaro. This assembly manual includes 426 pages with exploded views of all major components including:
- RS, SS and Z/28 option information
- Correct electrical, fuel, and vacuum hose routing
- Rear axle and exhaust system
- Front end sheet metal
- Subframe and radiator
- Front and rear suspension and steering
- Electrical for engine, interior and exterior
- RPO exploded views and component part number listings
- Much, much more!
This assembly manual also includes exploded views and assembly instructions for all major options, including, air conditioning, power steering, power brakes, console, gauges, radio and speakers, heater/cooling controls, windows, wheels, transmission and clutch pedal assemblies just to name a few. There are also emblem and stripe placement for some options included as well as torque and sealant information.
Please note: sample pictures are of 67 Camaro assembly manual. 69 similar.
Our assembly manuals are loose leaf (this is a benefit when working on a car over using a hard-bound manual as you can open to the page of your choice and it will stay there without you having to hold it open). Our manuals are 3-hole punched reprints of the original manual used at the factory. Because of this, you may find some pages that are very light or contain so much background noise, they are difficult to read. Nevertheless, we have intentionally included these pages as we feel any information you can get off bad pages is a bonus. We are confident that this manual is the best print on the market.
